This fan is compatible with our 24"14"x4" Mini-Pleat H14 HEPA Filter and all filter sizes below it for building a laminar flow hood.

Introducing our high-performance fan, a robust and reliable solution for all your cooling and ventilation needs. This fan is designed for demanding applications where efficiency and durability are paramount, making it ideal for a variety of environments from industrial to commercial settings.

High-Performance EC Centrifugal Fan – 110/115V

• Power Supply: Single-phase, 110/115 VAC

• Frequency: 50/60 Hz

• Rated Speed: 1900 RPM

• Maximum Input Power: 85 W

• Maximum Input Current: 0.62 A

• Sound Level: 61 dBA

• Motor Type: External rotor EC motor

• Motor Protections:

  • Locked rotor protection

  • Thermal protection

  • Under- and over-voltage protection

  • Overcurrent protection

  • Soft start

• Certifications: CE, RoHS compliant

• Operating Temperature Range: -25°C to 60°C

• Operating Humidity Range: 5%–90% RH

• Ingress Protection Rating: IP55

• Rotation Direction: Clockwise (viewed from rotor side)

• Impeller Material: Plastic

• Axial Runout: < 0.5 mm

• Radial Runout: < 0.5 mm

• Overall Dimensions: 246.9 × 220.5 × 130 mm

• Cable Length: 500 ±20 mm

• Additional Features:

  • Electrophoresis-treated rotor surface for improved corrosion resistance

  • Designed for reliable, long-term operation

Note: Always verify dimensions and electrical specifications of your existing fan before ordering to ensure proper fit and compatibility.
